Cycle Mode

Forced convection

Function

Temp. Range

RT+10-300℃

Temp. Resolution Ratio

0.1℃

Temp. Motion

±1℃

Temp. Uniformity

±2.5%

Structure

Inner Chamber

SUS304

Outer Shell

SUS304

Insulation layer

High quality rock wool board(with CE)

Heater

Stainless steel heater

Power rating

0.8kW

1.2kW

1.6kW

2.0kW

2.3kW

3.0kW

Exhaust hole

φ35mmtop(with function of test hole)

Rear exhaust

Controller

Temp. control mode

Two temperature section PID intelligent

Temp. setting mode

Touch button setting

Temp. display mode

Measuring temperature display on upper LCD screen, setting temperature  display on the lower screen

Timer

0-9999min(with timing wait function)

Operation function

Fixed temperature operation, timing function, auto stop.

Additional function

sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory

Sensor

PT100

Safety Device

High precision digital independent temperature limiter, over temperature audible and visual alarm

Specification

Inner Chamber size(W*L*H)

(mm)

310*310*310

350*350*350

400*360*450

450*420*450

500*450*550

600*500*750

Exterior size (W*L*H)(mm)

450*500*690

490*540*730

540*550*830

590*610*830

640*640*930

735*835*1115

Packing size (W*L*H)(mm)

550*585*845

590*625*885

640*635*985

690*695*985

740*725*1085

857*885*1287

Volume

30L

45L

65L

85L

125L

230L

Max Shelf number

5

6

8

8

11

17

Load per rack

15kg

Shelf space

40mm

35mm

Power rating (50/60HZ)

AC220V/3.6A

AC220V/5.5A

AC220V/7.2A

AC220V/9.0A

AC220V/10.5A

AC220V/13.6A

NW/GW (kg）

33/37

37/43

44/49

50/56

60/66

94/120

Accessory

Shelf

2

Shelf frame

4

optional accessories

Spare shelf, RS-485 interface, program controller, U-disk storage,3.5 inch color touch screen temperature controller
